Thread connect quick coupling
HG
Application:
Telehandlers, Manufacture Of Precast Concrete Components Into Vibrating Molds
Interchangeable with the following products:
Dnp VDV1,Faster VV, Holmbury PLC
Telehandlers, Manufacture Of Precast Concrete Components Into Vibrating Molds
Interchangeable with the following products:
Dnp VDV1,Faster VV, Holmbury PLC
Quantity
Interchange: Dnp VDV1 /Faster VV Material: Carbon Steel
Available Size: From 1/4’’-1’’ Available Thread: NPT, BSP Operating pressure: Up to 350 bar
Features:
1. High-pressure screw couplings
2. Oil Flow to 80 Lt/Min
3. Quick and secure connections with poppet-style valve design
4. Constructed with durable steel and brass materials
5. Screw-together design allows for easy installation (even with residual system pressure)
6. The set includes both male and female couplers for interchangeability
7.1/2"size suitable for a wide range of hydraulic systems
8. Compatible with Faster VV Interchange series of couplers.
